Home / Special Shape Window
Special Shape Window
 Opening Style:  Custom
 Thermal Insulation:  U≤ 0.5W/㎡K
 Acoustic Performance:  ≤ 45 DB
 Air Tightness:  ≤ 0.4m³(㎡h)
 Wind Load Resistance:  ≥ 2.8 KPa
 Water Penetration:  ≥ 800Pa
 Standard:  AS2047, NFRC
 Warranty: 10 Years
 Application: Residential, Commercial
 Performance: Thermal Broken, Soundproof
 Main Market: AU, USA
Inquiry now
Technical Specs
Hi-Tech profile and reinforced material
Reinforced glass fiber thermal insulation bar with high loading capacity
Pressure extrusion for higher strength level
Coex wire seal to protect against moisture
Multi-point hardware lock system for weather sealing and burglarproofing
Truss structure design for increased structural strength
Tilt-turn system achieves the AAMA rating of CW-PG60
Corner locking key ensures the smooth surface joint and improves corner stability
Glass panel EPDM foam weather sealing strip used for better performance and easier maintenance than standard glue
Color & Coating Options
WeiXiang Commen Color: Frosted Black, White Powder Coating
Silver grey powder coating, Silver anodising with INTERPON powder
Woodland grey(Satin), Ironstone(Stain), Shale Grey(Satin)
Ultra Silver(Gloss), Dune(Sain), Paperbark(Satin), Primrose(Gloss)
White Birch(Gloss), Surfmist(Matt), Architectural White(Satin)
Pearl White(Gloss), Silver Pearl Kinetic(Satin), Black(Satin)
Monument(Matt), Clear, Residential Bronze
Cedar, Mahogany, Honey Gum, Snow Gum
Select between factory-prefinished colors for fast delivery, or customized colors to better match your home
Glass Options
Single Glass(5mm, 6mm, 8mm, 10mm….)
Laminated Glass(5mm+0.76pvb+5mm)
Double Toughened Glass(5mm+12air+5mm)
Toughened Laminated Glass(5mm+12air+0.76pvb+5mm)
Triple Toughened Glass(5mm+12air+5mm+12air+5mm)
Thickness of single glass: 5-20mm
Glass types: Frosted glass, Toughened glass, Low-e coated glass
Special performance glass: Fireproof glass, Bulletproof glass
Select from various types of glass, including but not limited to: tinted, low-e, sound-proof and burglarproof.
Screen Options
Screen Types: Stainless Steel Mesh, Fiberglass Screen, Retractable Screen
Fly and insect screen is a great way to keep insects out of your home
All fly screens are supplier with fibreglass mesh as standard
Midrail and handle hights depend on customer requirements
Fixed Screen is easy installation and removal
In-swing Screen can help you enjoy nature and keep the bugs out
Rolling Screen let you enjoy an unobstructed view when rulled up
The mesh screen is color coated together with the window to match perfectly.
Our screens are manufactured using aluminum alloy; strong enough to keep the mesh tight for years to come.
Grille Options
Grilles between glass increase visual appeal and allows for easier glass cleaning
The grilles consist of a spacer bar placed between the panes of the insulating glass
It is available in the color that matches the exterior color of the window you choose
SDL Grilles are permanently attached to both the interior and exterior glass
Shadow bars that are placed between the two panes of insulating glass
Truss structure design for increased structural strength
Tilt-turn system achieves the AAMA rating of CW-PG60
Corner locking key ensures the smooth surface joint and improves corner stability
Glass panel EPDM foam weather sealing strip used for better performance and easier maintenance than standard glue
Hardwares&Accessories Options
Australia Doric hardware
America CMECH hardware
German Hoppe hardware
China top SMOO Hardware
German SIEGENIA hardware
China top KINLONG hardware
German ROTO hardware
German GEZE hardware
WeiXiang always choose seriously hardwares&accessories for customers with 10 years warranty
Customize Your Special Shape Window
In the past few years, WeiXiang made various kinds of aluminium windows, inculding sliding windows, casement windows, bifold windows, awning widnows, tilt and turn windows, fixed windows,hung windows and other kinds of windows.
Different Customer has Different Choice.
We are capable of customizing any kind of aluiminium windows according to customer’s demand. Superhouse brand spreads all over the world, especially in Australia, America, Canada, Britain, and so on.
WeiXiang windows doors are widely used in residential buildings, commercial buildings, and other public buildings, including private house, apartment, hotel, office building,school, commercial building, hospital, stations, etc.
More details
WeiXiang Certificate
WeiXiang dedicate in making your home more valuable with our windows and doors which are renowned by fine craftsmanship, innovation and long life durability. We provide our customers with our best products and service which meet the Australia standard.

In order to take a place in America market,we have got local certificates by 3 years’product design and test. such as Nfrc standard, Florida approved, Miami Dade approved.
